Chinese Small Farm Tractor 4x4 Mini Tractor Walking Tractor Price Tractor
four-wheel drive two series the mini tractor It is suitable for gardening, greenhouse,lawn and family work.
Highlights: Economical and practical
Working land-form: Suitable for plain working
Working land-form: Plain, hills and mountain region working, stable structure could deal with all kinds of land-forms
wheel tractor is Strong Power, Reliable Feature as blow
1,Equipped with famous engine, four-wheel drive, new diesel power, low fuel consumption, large torque reserve, strong power;
2,Power emission upgrade, performance upgrade
Farm tractor is Advanced Technology, reasonable specification
1,Gearbox using big Ningbo 8+8 or 8+2 side gear, speed matching reasonable, high efficiency, can meet a variety of work needs;
agriculture farm tractor is High Efficiency, flexible operation
Strong pressure lifter, independent oil, can maintain the cleanliness of hydraulic oil, avoid stuck valve, extend the service life of hydraulic components,Simple structure, convenient disassembly and installation
Power output 540/720 RPM/min
1. Famous brand: brand with long history and good reputation
2. Top quality: successfully passed ISO 9001 international quality certification system and China 3C quality system
Main technical parameters of farm tractor
| Model | HRE504 | HRE604 | HRE704 |
| Type | 4×4 wheel | ||
| (mm)Boundary Dimensdsion(L*W*H) | 3660×1350×2260 | ||
| (kw/rpm) | 51.5/2500 | ||
| (KN)Maximum traction force | ≥10.4 | ||
| (KN)Maximum lifting force | ≥12.5 | ||
| Transmission form | 8+2 | 8+2 or 8+8 | 8+2 or 8+8 |
| (r/min)PTO Revolving Speed | 540/720 | ||
| Multiple Spline of PTO | 8Tooth rectangle | ||
| Hydraulic output | 2 groups | ||
| Tine (front/Rear) | 7.50-16/11.2-28 | ||
| (mm)Front wheel track | 1000,1050,1200,1250,1300 | ||
| (mm)Rear wheel track | 1000-1300 | ||
| (Km/h)Speed range | 2.42~32.43 | ||
